Description
Spesifikasi :
- Rated Input : 6W (100V Line), 3W (70V Line)
- Rated Impedance : 100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 10 kΩ (1 W) | 70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
- Sensitivity : 90 dB (1 W, 1 m) (500 Hz – 5 kHz, pink noise)
- Frequency Response : 100 Hz – 18 kHz (peak -20 dB)
- Speaker Component : 12cm (5”) cone-type
- Dimensions for Fixing Hole : Mounting Hole : ⌀145±5mm (⌀5.71” ± 0.2”) | Ceiling Thickness 5 – 25mm (0.2” – 0.98”)
- Speaker Mounting Method : Spring Clamp
- Finish : Baffle: Polypropylene resin, white (RAL 9010 equivalent) | Grille: Surface-treated steel plate net, white (RAL 9010 equivalent), paint
- Dimensions : ⌀168 x 77 (D) mm (⌀6.61” x 3.03”)
- Weight : 470g (1.04 lb)
- Accessory : Paper pattern 1
