Description
Spesifikasi :
- Rated Input : 6W (100V Line)
- Rated Impedance : 100V Line : 1.7 k (6W), 3.3 k (3W), 6.7 k (1.5W), 13 k (0.8W)
- Sensitivity : 90 dB (1W, 1m) (500 Hz – 5000Hz, pink noise)
- Frequency Response : 55 Hz – 18000 Hz (peak -20 dB)
- Speaker Component : 12cm (5”) cone-type
- Dimensions for Fixing Hole : Mounting hole: ⌀150±3mm (⌀5.91” ±0.12”). Ceiling Thickness : 5 – 25mm (0.2” – 0.98”)
- Speaker Mounting Method : Spring Clamp
- Applicable Cable : 600V vinyl-insulated cable (IV wire or HIV wire), Solid copper wire : ⌀0.8 – ⌀1.6mm (equivalent to AWG 20 – 14) 7-core twisted copper wire : 0.75 – 1.25mm2 (equivalent to AWG 18 – 16)
- Connection : Push-in Connector (Bridging terminal-2 branch type)
- Finish : Baffle: Steel Plate, white (RAL 9016 aquivalent), paint. Grille : Surface-treated steel plate net, white (RAL 9016 equivalent), paint
- Dimensions : ⌀180 x 72 (D) mm (⌀7.09” x 2.83”)
- Weight : 620g (1.37 lb)
- Accessory : Paper pattern 1
