Description
Spesifikasi :
- Rated Input : 6W (100V Line), 3W (70V Line)
- Rated Impedance : 100V Line : 1.7 kΩ (6W), 3.3 kΩ (3W), 6.7 kΩ (1.5W), 13 kΩ (0.8W). 70V Line : 1.7 kΩ (3W), 3.3 kΩ (1.5W), 6.7 kΩ (0.8W), 13 kΩ (0.4W)
- Sensitivity : 95 dB (1W, 1m) (330 Hz – 3.3kHz, pink noise)
- Frequency Response : 100 Hz – 20 kHz (pink noise -20 dB)
- Speaker Component : 12cm (5”) cone-type
- Dimensions for Fixing Hole : Mounting Hole : ⌀156±3mm. Ceiling Thickness 5 – 25mm (0.2” – 0.98”)
- Speaker Mounting Method : Spring Catch
- Applicable Cable : Solid wire : ⌀0.5 – ⌀3.0mm2 (AWG 20 – 12)
- Connection : Push Wire Connection (Bridging terminal-2 branch type)
- Finish : Frame : Steel Plate, white (RAL 9016 equivalent), paint. Grille : Steel net, white (RAL 9016 equivalent), paint. Fire Dome : Steel plate, plating
- Dimensions : ⌀180 x 5 (exposed section) + 100 (D) mm (⌀7.09” x 0.19” + 3.94”)
- Weight : 1kg (2.2 lb)
