Dual-Channel Power Amplifier

Description

Spesifikasi :

Non-CE Model

• Power Source : 100 – 240 V AC, 50/60 Hz
• Amplification System : Class D
• Power Consumption : 1100 W *¹
• Input : CH 1-2: 20kΩ (balanced) / 10kΩ (unbalanced), 0.775/1.0V/32dB*², XLR-F connector
• Output : LINK CH 1-2: XLR-M connector
  Speaker 1-2:
  2 channels: 700 W × 2 (8 Ω)*³, 1250 W x 2 (4 Ω)*⁴
  1 channel (BRIDGE): 2500 W × 1 (8 Ω)*⁴
  NL4 SPEAKON connector
• Frequency Response : 20 Hz – 20 kHz (±3 dB)
• Total Harmonic Distortion : ≤ 0.15 %
• S/N Ratio : ≥ 100 dB
• LED Indicator : Protect (Red) / Clip (Red) / -5dB (Green) / -10dB (Green) / -20dB (Green) / Signal (Green) / Power (Green)
• Cooling : Air flow from front to rear
• Operating Temperature: 0 ℃ to +35 ℃ (32 ゜F to 95 ゜F)
• Operating Humidity : 80 %RH or less (no condensation)
• Finish : Case: Plated steel sheet, black
• Dimensions : 483 (W) × 89 (H) × 305 (D) mm
• Weight : 6.1 kg
• Accessory : Power cable …1

CE Model

• Power Source : 100 – 240 V AC, 50/60 Hz
• Amplification System : Class D
• Power Consumption : 1100 W *¹
• Input : CH 1-2: 20kΩ (balanced) / 10kΩ (unbalanced), 0.775/1.0V/32dB*², XLR-F connector
• Output : LINK CH 1-2: XLR-M connector
  Speaker 1-2:
  2 channels: 700 W × 2 (8 Ω)*³, 1250 W x 2 (4 Ω)*⁴
  1 channel (BRIDGE): 2500 W × 1 (8 Ω)*⁴
  NL4 SPEAKON connector
• Frequency Response : 20 Hz – 20 kHz (±3 dB)
• Total Harmonic Distortion : ≤ 0.15 %
• S/N Ratio : ≥ 100 dB
• LED Indicator : Protect (Red) / Clip (Red) / -5dB (Green) / -10dB (Green) / -20dB (Green) / Signal (Green) / Power (Green)
• Cooling : Air flow from front to rear
• Operating Temperature : 0 ℃ to +35 ℃ (32 ゜F to 95 ゜F)
• Operating Humidity : 80 %RH or less (no condensation)
• Finish : Case: Plated steel sheet, black
• Dimensions : 483 (W) × 89 (H) × 305 (D) mm
• Weight : 6.4 kg
• Accessory : Power cable …1
